Overview
The Vault Native Application is a required component for enabling browser-based integration between Vault and third-party clinical and reporting tools. It acts as a bridge between the Chrome browser extension and desktop software.
Compatible with:
- Advanced Visualization Tools (3D rendering and diagnostic imaging platforms)
- Epic (EHR integration)
- Powerscribe
- Other supported 3rd-party application requiring native host messaging
Note: Chrome Native Messaging allows browser extensions to communicate with locally installed desktop applications. Vault uses this mechanism so its browser extension can invoke features in the Vault desktop app and connected clinical tools.
System Requirements | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Before installing, confirm the target system meets the following requirements: | ||||||||||||||
| ||||||||||||||
Download .NET and ASP.NET Core runtimes from Microsoft: https://dotnet.microsoft.com/en-us/download/dotnet/10.0 |
Digital Certificate |
|---|
Vault executables must be digitally signed so Windows SmartScreen and endpoint security tools recognize them as trusted. |
Current State A production certificate from a trusted Certificate Authority is in progress. Until it is issued, a self-signed certificate is active. Users must manually install the CA certificate — see the Install Self-Signed Certificate section below. Once Production Certificate is Issued When the production certificate is deployed, the Install Self-Signed Certificate steps can be retired. Vault will be automatically trusted by Windows with no manual certificate steps required. |
Install Self-Signed Certificate |
|---|
Required until the production Authenticode certificate is issued. Skipping this step will cause Windows SmartScreen to block or warn against the Vault installer. |
Follow these steps to add the Vault CA certificate to the Windows Trusted Root Certification Authorities store: 1. Obtain the CA Certificate File Get the .cer or .crt file from your system administrator or the Vault distribution package. 2. Open Certificate Manager Press Win + R, type certmgr.msc, and press Enter. 3. Navigate to Trusted Root Certification Authorities In the left panel, expand "Trusted Root Certification Authorities" and click "Certificates". 4. Import the Certificate Right-click "Certificates" → All Tasks → Import... to launch the Certificate Import Wizard. 5. Complete the Wizard Click Next, browse to the .cer / .crt file, confirm the destination store is "Trusted Root Certification Authorities", and click Finish. 6. Confirm the Security Warning Click Yes when Windows displays a security warning. The certificate will appear in the trusted store. 7. Verify Confirm the Vault CA certificate is listed under Trusted Root Certification Authorities → Certificates. |
Video walkthrough available at: https://www.youtube.com/watch?v=7oB1my_SAps |
Installation Scenarios |
|---|
Both options use the same installer. The difference is how the Chrome Native Messaging Host is configured. Choose the option that matches your environment. |
Option A — Chrome Extension from Chrome Web Store Use this option when the Vault Chrome extension is installed directly from the Chrome Web Store. This is the standard installation flow.
WARNING: Do NOT run the installer as Administrator. Always launch by double-clicking. Vault will request elevation only for specific steps that require it. Running the full installer as Administrator will cause configuration errors.
Chrome Native Messaging is configured automatically in Option A. No additional configuration is required. |
Option B — Chrome Extension from Local Folder Use this option when the Vault Chrome extension is loaded from a local folder (unpacked extension mode). This requires a manual configuration step after installation.
|
Start-Process -FilePath \ C:\Users\[YOUR_USERNAME]\AppData\Local\Vault\Data\Cli\Vault.Cli.exe ` -ArgumentList @( "create", "chrome-native-messaging-host", "--overwrite", "--name", "local.integration.compass", "--type", "stdio", "--description", "`"App that makes possible to discover Vault API in the browser.`"", "--path", "`"C:\Users\[YOUR_USERNAME]\AppData\Local\Vault\current\Compass\Compass.exe`"", "--allowedOrigins", "`"chrome-extension://[EXTENSION_ID]/`"" ) ` -Verb RunAs |
[YOUR_USERNAME] — Your Windows username (e.g., jsmith) [EXTENSION_ID] — Found in Chrome at chrome://extensions while in Developer Mode |
Notes and Best Practices |
|---|
|
Quick Reference — Installation Checklist | Action |
|---|---|
Install .NET Runtimes | Install .NET Runtime 10.0.2 and ASP.NET Core Runtime 10.0.2 |
Install CA Certificate | Add self-signed CA cert to Trusted Root Certification Authorities (see Install Self-Signed Certificate section) — skip once production cert is issued |
Download Installer | Get Vault-win-Setup.zip from your system administrator or repository |
Run Installer | Double-click Vault-win-Setup.exe — do not run as Administrator |
Configure Messaging Host (Option B only) | Run PowerShell command with correct username and extension ID |
Verify Installation | Launch Vault and confirm connection with target 3rd-party application |
